Earthing Clamp/Lock-Out Padlock Solution

A new solution consisting of an earthing clamp paired with a lock-out padlock, both using the same retaining key. This solution imposes a sequence for the installation of the equipment during lock-out as well as a disassembly sequence during the unlocking process. It prevents switching back on the system as long as the clamp is still in place as this dangerous event may occur with multiple and remote systems.

The padlock paired with the clamp needs to be complemented by the personal lock-out padlock belonging to authorised employee who locks equipement.


Technical Characteristics

  • Short-circuit rating: 20 kA/1s.
  • Suitable for low and high voltage installations.
  • Connection for cable with a max. cross section of 50 mm2.
  • Clamping capacity:
    • Ø 6-26 mm
    • flat 0-30 mm


Dimensions/Weight

  • Clamp: 70 x 90 x 50 mm
  • Padlock: 39 x 86 x 19 mm
  • Weight of set: 1 kg
  • Weight of clamp only: 820 g
