levafrbfi

LEVITON AFRBF-I Blank Face AFCI Receptacle 20 A, WD-6 Ivory

Price $78.15 / EA
Inventory
Available for backorder
Qty EA
Manufacturer:LEVITON
Manufacturer #:AFRBF-I

Description

The SmartlockPro® outlet branch circuit (OBC) AFCI receptacle offers advanced technology to help protect against electrical fires resulting from arc-faults. Designed to detect a wide range of potentially hazardous arc-faults resulting from damage in branch circuit wiring as well as extensions to branches such as appliances and cord sets the OBC AFCI responds by interrupting power. This helps reduce the likelihood of the home’s electrical system being an ignition source of a fire. Often unseen, arc-faults can occur anywhere in the home’s electrical system including within walls, at loose electrical connections or within electrical cords accidently damaged by impinging furniture. AFCI’s are now required by the National Electrical Code® in many areas of the home.

Specifications

Brand Name Leviton Sub Brand TAMPER RESISTANT GFI RECEPTACLES
Item Name AFCI Receptacle Type Blank Face
Grade Commercial, Specification Voltage Rating 125 VAC
Amperage Rating 20 A Wire Type Self Grounding
Number of Poles 2 Number of Wires 3
Connection Type Back and Side Wired NEMA Rating WD-6
Conductor Size 14-10 AWG Material Polycarbonate
Color Ivory Dielectric Strength 1250 VAC
Grounding Self Mounting Type Wall
Temperature Rating -35 °C to 66 °C Environmental Conditions UL 94-V2 Flammability
Standards ANSI C-73, CSA C22.2 No. 42, NOM 057, UL1699.A File E342815, UL498 UL Listed UPC 078477622476

Packages

1 - Unit 10 - Crate 3360 - Pallet
